220PCS PE Double Splice Tube Butt Shrinkable Terminal Insulated Crimp Heat Shrink Wire Connector Kit

Place of Origin : Guangdong, China

Model Number : yellow rose red blue

MOQ : 2

Type : SPLICE

Color : Yellow Rose red Blue

Material : Nylon+Tinned

Certificate : ISO9001 SGS CE CQC ROHS

Product name : Solder Seal Wire Connectors

Wire range : 10-12/14-16/ 18-22 AWG

Package : 180/200/210/220/240/250/270/480pcs/BOX

MOQ : 1box

Item : Heatshrink Tubing

Application : Wire Connection

Usage : Connecting Cable

Contact Now

Each box contains:
Heat Shrink butt connector
Heat Shrink Ring Terminal (#10)
Heat Shrink Ring Terminal (1/4")
Heat Shrink Ring Terminal (5/16")
Heat Shrink Ring Terminal (3/8")
Male Quick Disc
Female Qucik Disc
Fork Terminal(#10)

Property	Specification Requirement	Test Method	Typical Value
Tensile strength(Room temp.)	Min.10.4Mpa	UL224	17.2Mpa
Elongation at break(Room temp.)	Min.200%	UL224	280%
Tensile strength after aging(158℃ 168hrs)	Min.7.3Mpa	UL224	11.5Mpa
Elongation after aging(158℃ 168hrs)	Min.100%	UL224	200%
Voltage withstand(Uh-aged)	Withstand 2.5kv for 1 minute and breakdown	UL224	pass
Voltage withstand(Aged)	Withstand at least half of un-aged breakdown voltage for 1 minute and breakdown	UL224	pass
Copper corrosion(158℃ 168hrs)	No corrosion of bare copper	UL224	No sign of deg.
Copper stabiity(158℃ 168hrs)	No sign of degradation (min.elongation 100%)	UL224	pass
Cold blend(-30℃ 1hrs)	No crack	UL224	pass
Maximum secant modulus(2%)	173Mpa	UL224	pass
Volume resistivity	Min.1014Ω.m	UL224	pass
Heat shock(250℃ 4hrs)	No crack	ASTM D2671	pass
Dielectric strength	>15.8kv/mm	ASTM D2671	>25kv/mm
